Facade wall cladding/gutter /roof color coated aluminium coil

FOB Reference Price:Get Latest Price
$2,160.00 - $3,880.00 / Ton | 6 Ton/Tons (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Yatai
Model Number:
AT-001
Application:
ACP, Roofing, Ceiling
Thickness:
0.02mm-3.0mm
Surface Treatment:
Coated
Width:
Standard 1240mm
Grade:
1000 Series
Alloy Or Not:
Is Alloy
Temper:
O - H112
Color:
As per your sample or our color chart
OD:
1200mm
ID:
150mm, 405mm, 505mm
Alloy:
A1100, A3003, A3005, A8011 etc.
MOQ:
6Tons
Certificate:
SONCAP, ISO9001:2000, CE
Supply Ability
Supply Ability:
6000 Ton/Tons per Month
Packaging & Delivery
Packaging Details
1, seaworthy packing with wooden cases/plates for long distance transportation.
2, around 20tons per 20ft container.
as the pictures showed
Port
Qingdao
Lead Time :
15-20 days after deposit

Facade wall cladding/gutter /roof color coated aluminium coil/color coated aluminum sheet/painted aluminum sheet

Product Description

Facade wall cladding/gutter /roof color coated aluminium coil/color aluminum sheet/painted aluminum sheet

Alloy

1000 series,3000series,8000series

Temper

H16,H26 and so on

Thickness

From 0.02mm to 3.0 mm

Width

From 40- 1600 mm

Diameter

Standard diameter:1100mm

Interior diameter:150mm, 405mm,505mm

Weight

2.0-3.0 Tons/coil

Coating

PVDF, PE or AC

Surface

Embossed, mill finish, coated

Color

RAL or Customized

Gloss

10-90%(EN ISO-2813:1994)

Coating Thickness

PE: more than 18 micron

PVDF: more than 25 micron

Coating Hardness(pencil resistance)

More than 2h

Coating Adhesion

5J(EN ISO-2409:1994)

Impact Resistance

No peeling or cracking(50 kg/cm,ASTMD-2794:1993)

Flexibility (T-bend)

≤2T

MEK Resistance

More than 100

We can produce the thickness from 0.02mm to 3.0mm, the width from 40mm to 1600mm, the paint including AC/PE/PVDF/HDPE/FEVE. The Alloy No. is 1000 series, 3000 series and 8000 series.

Features of color coated aluminum coil / sheet / strip:

1) Light weight, high strength, extreme rigidity, superior impact resistance

2) Excellent surface flatness and smoothness

3) Heat insulation, sound insulation, fire-resistance

4) Acid-resistance, alkali-resistance, good weatherproofing and non-resonance

5) Various uniform colors ,can be easily processed and fabricated, quickly installed

6) Elegant and magnificent, good flexibility fits various designs

7) Easily maintenance, simply cleaning



Product Application

Packaging & Shipping





Company Information



Shandong AT New Material And Technology Co., Ltd. was established in 2010. It is one of the biggest manufacturers of color coated aluminum coil, embossed aluminum coil and aluminum ceiling in China.

We have got ISO9001:2008 and SONCAP certifications in 2013. We have 4 color coating lines, 2 slitter lines and 2 embossing lines. Our coating lines are high-speed automatic production line from Germany. Production capacity reaches 36000MT per year.

Our products are widely used in the field of aluminum composite panel, aluminum roofing, aluminum ceiling, aluminum curtain wall, roller shutter doors, aluminum can, aluminum cap rain-gutter and other indoor, outdoor decoration.

Also, we have good cooperation with some famous suppliers, such as PPG, Nippon, Chinalco, Southwest Aluminum etc. Our engineers have rich experience in color coating area for more than 10 years. With high quality, very competitive price, precision equipment and famous brand raw material, our products are very popular both in domestic and abroad market, such as USA, Brazil, Vietnam, Russia, UAE, Nigeria and all over the world.
